SEMI M80 - Specification for Front-Opening Shipping Box Used to Transport and Ship 450 mm Wafers

Volume(s): Materials
Language: English
Type: Single Standards Download (.pdf)
Abstract

This Standard was technically approved by the Silicon Wafer Global Technical Committee. This edition was approved for publication by the global Audits and Reviews Subcommittee on October 19, 2015. Available at www.semiviews.org and www.semi.org in January 2016; originally published November 2011; previously published May 2014.



This Standard specifies the front-opening shipping box (FOSB) used to ship 450 mm wafers from wafer suppliers to their customers (typically IC manufacturers), while maintaining wafer quality.



This Standard is intended to set an appropriate level of specification that places minimal limits on innovation while ensuring interoperability at all mechanical interfaces.



This Standard assumes that the 450 FOSB is used in loading raw silicon wafers after inspection in Si suppliers and also used in acceptance and inspection, after which raw silicon wafers are transferred to another carrier at device makers. The 450 FOSB is not intended to be used in IC manufacturing processes. It is recommended that wafers be transferred from the 450 FOSB to a 450 FOUP using automated methods.



Referenced SEMI Standards

SEMI E144 — Specification for RF Air Interface Between RFID Tags in Carriers and RFID Reader in Semiconductor Production and Material Handling Equipment
SEMI E154 — Mechanical Interface Specification for 450 mm Load Port
SEMI E158 — Mechanical Specification for FAB Wafer Carrier Used to Transport and Store 450 mm Wafers (450 FOUP) and Kinematic Coupling
SEMI E162 — Mechanical Interface Specification for 450 mm Front-Opening Shipping Box Load Port
SEMI M1 — Specification for Polished Single Crystal Silicon Wafers
SEMI M74
— Specification for 450 mm Diameter Mechanical Handling Polished Wafers

Member Price: $225.00
Regular price Non-Member Price: $150.00
