T00400 - SEMI T4 - Specification for 150 mm and 200 mm Pod Identification Dimensions

SEMI T4 - Specification for 150 mm and 200 mm Pod Identification Dimensions -

Member Price: $144.00
Non-Member Price: $187.00

Volume(s): Traceability
Language: English
Type: Single Standards Download (.pdf)
SEMI Standards Copyright Policy/License Agreements

Revision: SEMI T4-0301 (Reapproved 0419) - Current

Revision

Abstract

The purpose of this Specification is to ensure dimensional compatibility when mounting pod identification tags and tag identification devices.

　

The scope of this Specification is to define:

  • free space at a pod to allow the mounting of a pod identification tag, and

  • free space to allow data transmission.

　

This Specification is applicable to 150 mm and 200 mm Standard Mechanical Interfaces (SEMI E19). The space required for pod handling per SEMI E47 is considered.

　

Referenced SEMI Standards

SEMI E15 — Specification for Tool Load Port

SEMI E19 — Specification for Standard Mechanical Interface (SMIF)

SEMI E47 — Specification for 150 mm/200 mm Pod Handles
